Wire Voltage Drop Calculator
Calculate the voltage drop along any wire run.
Enter wire gauge, length, current, and material to find voltage loss and check if wiring meets code.
Voltage drop is the reduction in electrical potential as current flows through a wire. Long wire runs, thin wires, and high currents all increase voltage drop. Too much voltage drop causes equipment to malfunction, motors to overheat, and lights to dim.
The formula:
Voltage Drop (V) = I × R_total
R_total = 2 × L × ρ / A
Where:
- I = current (Amperes)
- L = one-way wire length (meters or feet)
- ρ = resistivity of the conductor material (Ω·m)
- A = cross-sectional area of the wire (m²)
- The factor of 2 accounts for the return wire (complete circuit)
Resistivity of common conductor materials, at 20°C:
- Copper: 1.724 × 10⁻⁸ Ω·m (most common, lowest resistance)
- Aluminum: 2.82 × 10⁻⁸ Ω·m (the EC-grade alloy cable is actually drawn from; physics tables quote 2.65 for the pure metal, which nobody wires a house with)
- Silver: 1.59 × 10⁻⁸ Ω·m (best conductor, rarely used due to cost)
Why NEC tables give a bigger answer than this page does. Copper resistance climbs about 0.4% per degree, and NEC Chapter 9 Table 8 is written for a conductor at 75°C, the temperature a wire near its rating actually reaches. That puts the code figures about a quarter above the 20°C numbers used here: 14 AWG is 2.53 Ω per 1,000 ft cold and 3.14 Ω hot, which is 24% more. Use this page for the physics and a wire sized off Table 8 when an inspector is involved.
AWG (American Wire Gauge) cross-sectional areas:
| AWG | Diameter (mm) | Area (mm²) | Max Current (A) |
|---|---|---|---|
| 18 AWG | 1.02 mm | 0.823 mm² | 7–10 A |
| 16 AWG | 1.29 mm | 1.31 mm² | 13 A |
| 14 AWG | 1.63 mm | 2.08 mm² | 15–20 A |
| 12 AWG | 2.05 mm | 3.31 mm² | 20 A |
| 10 AWG | 2.59 mm | 5.26 mm² | 30 A |
| 8 AWG | 3.26 mm | 8.37 mm² | 40–55 A |
| 6 AWG | 4.11 mm | 13.3 mm² | 55–75 A |
| 4 AWG | 5.19 mm | 21.1 mm² | 70–95 A |
| 2 AWG | 6.54 mm | 33.6 mm² | 95–130 A |
Acceptable voltage drop limits:
| Application | NEC Recommendation | Typical Limit |
|---|---|---|
| Branch circuits | ≤ 3% | 3.6 V on 120 V |
| Feeders | ≤ 3% | 7.2 V on 240 V |
| Total (combined) | ≤ 5% | 6 V on 120 V |
| DC systems (solar, automotive) | ≤ 2–3% | 0.3 V on a 12 V circuit |
Worth saying plainly: none of these are code requirements. NEC 210.19(A) and 215.2(A) put them in informational notes, which means an inspector cannot fail you for a 4% branch circuit. They are there because equipment misbehaves below them, not because the book forbids it.
Practical notes:
- Voltage drop matters most on long runs. A 50-foot (15 m) circuit rarely has issues; a 200-foot (61 m) run often does.
- If voltage drop exceeds 3%, use the next larger wire gauge.
- Voltage drop causes heat in the wire, which is both inefficient and a fire hazard.
- Use copper for residential wiring; aluminum is acceptable for large service entrance conductors.
